EIP 4U 19-inch PoE server



Download brochure



A server with integrated Power over Ethernet ports.

ECOserver model EIP combines the extensive power and all of the other advantages of our popular EIB server model with special motherboards allowing us to integrate PoE switching functionality into the server chassis. ECOserver EIP provides a complete integrated solution designed to be a host for multiple PoE IP cameras. ECOserver model EIP can be configured as a DHCP server so that it is able to automatically find each camera as it becomes live, and automatically issue that camera with an IP address. ECOserver model EIP is a specialised server for IP camera hosting.

IP camera support during Power cuts. Since the PoE functionality is supported by the internal power supply of the ECOserver, a UPS supporting the ECOserver means that camera and other PoE IP security devices will carry on working even during a power cut. ECOserver model EIP is designed as a building security and access control server.



Secure PoE IP camera network. ECOserver’s integrated PoE technology generates a completely secure camera network which cannot be hacked electronically since it offers no external network connection. Of course we have another discrete network port allowing downloads and management functions from another network or a remote location, but the uncompromised PoE network is essentially 100% secure. ECOserver model EIP is a network ready camera recorder for IP cameras and/or analogue cameras.

Fastest PoE network for IP cameras. The unique nature of the way in which ECOserver presents and manages PoE technology means that full Ethernet bandwidth is available for every four ports in the ECOserver PoE network, which means that you never have any data bottlenecks causing frame loss or any other network congestion problems which can be associated with conventional PoE deployment. ECOserver model EIP can be configured both as a camera server and a workstation for camera image viewing.

SPECIAL features of ECOserver model EIP

• Special Form Factors (we’ll build a server to fit wherever it needs to fit)

• Storage adapted to a customer’s needs

• Flexible configurations (an ECOserver can be both server and workstation for instance)

• Integrated PoE (Power over Ethernet) switch options for fast and easy camera network installation

• All PoE ports operate at a constant 15.4 watts for reliable camera support

• Long distance PoE (using Ethernet ofer coax technology) for bigger sites

• Ethernet over Coax modules for upgrading older camera installations to IP using existing coax cabling

• Mix and match Ethernet and analogue CCTV systems in one server

• Mix and match IP and coax cabling systems within one server

• Run multiple discrete camera networks within one server

• Up to 50 IP cameras supported per server.

• 100% secure and discrete camera networking

• Delivered with ECOserver logo, without logo or with your own brand

• Developed and produced in Europe

• Specials on demand with fast delivery

• Logistic (parts and complete servers stocked) services for projects

• Images on server for project supply, backup and special configurations

• Extra inventory carried for projects

• 3 years standard warranty (return to factory)

• Embedded / Long Life models available

• Assured stable configurations for 4 to 5 years for long rollout projects.

ECOserver’s energy saving measures

ECOserver products are built with a view to minimising power consumption, heat output and space requirements whilst providing the maximum practical processing power for the task given. Specific energy consumption for a real application can be calculated on request as a part of our specification and quotation process.



Physical design

Supplied as standard in black without the ECOserver logo with DVD or with a white front and the ECOserver logo and DVD. Other colours and custom livery and logo placement quoted upon request.











Download brochure

General Information



ECOserver model EIP is a universal 4U-high 19-inch server that features many unique properties, including:

*energy efficient, from only 45W;

*compact, depth only 40 cm;

*low noise level;

*maximum of 7 PCI slots;

*integrated Power over Ethernet (PoE) switch option;

*integrated frame grabber;

*integrated EoC (Ethernet over Coax) for longer distance camera support

.

Specific properties



Model EIP is a server that was (and is constantly being) developed especially for the high-end security market. PoE solutions are increasingly popular, and as well as the convenience of a switch integrated into the host server, our PoE out-performs many other systems as we provide full Ethernet bandwidth per four PoE ports, thus avoiding network congestion, with its attendant picture and storage problems. Model EIP can be configured as a DHCP server so that all of the cameras will be given an IP address automatically. All of the PoE ports are always 15.4 Watts. Model EIP also has space for an additional PCI or PCI-Express card, so you can place an extra network card, video card or even a frame-grabber card so as to make a hybrid server. Model EIP can mount up to 6 hard drives internally.

Target group



Model EIP is ideal for high end security projects, and makes an ideal camera network server, access control server, facility management server, building monitoring server etc. combined with a UPS you can create a mains-power independent solution.

For smaller installations (four cameras supported by an internal PoE switch), please see ECOserver model EEB/EEP

3 Years warranty on all ECOserver models.
